Range

1 ppm to 5%

Resolution

1 ppm (0.0001%)

Accuracy

1.00%

Result Units

%, ppm, ppt, mg/g, µg/g, mg, µg, mg/mL, µg/mL, mg/pc, µg/pc

Sample Type

Liquid or Solid* (external diss./extract.)

Titration Vessel

Operating volume between 100-200 mL

Reagent Handling System

Sealed system with integrated diaphragm air pump and beaker adapter

Generator Cell

Configuration

Fretted or Fretless(w/ or w/o diaphragm)

Generator Cell

Dosing

50-400 mA pulsed DC current

Determination

Pre Titration Conditioning

Automatic

Determination

Background Drift Connection

Automatic; User Selectable Value

Determination

Endpoint Criteria

Fixed mV persistence, relative drift stop, or absolute drift stop

Determination

Dosing

Dynamic

Determination

Result Statistic

Mean, Standard Deviation

Electrode

Type/Connection

Dual platinum pin, polarization electrode / BNC

Electrode

Polarization Current

1, 2, 5,10,15, 20, 30 or 40 µA

Electrode

Voltage Range

2 mV to 1000 mV

Electrode

Voltage Resolution

0.1 mV

Electrode

Accuracy (@25 °C/77 °C)

±0.1 mV

Graphic Display

5.7 (320 x 240 pixel) color LCD

Titration Methods

Additional Specification

Up to 100 (standard and user)

Data Storage

Up to 100 titration and drift rate reports can be stored
