Inductive Sensor
Product Details:

Brand	P&F
Sensor Type	Inductive Sensor
Model Name/Number	NBB5-18GM60-WO
Output Type	Two Wire
Switching function	Normally closed (NC)
Rated operating distance	5 mm
Installation	Flush
Output polarity	AC
Assured operating distance	0 to 4.05 mm
Actual operating distance	4.5 - 5.5 mm typ. 5 mm
Reduction facto	0.2
Operating voltage	20 to 253 V
Switching frequency	20 Hz
Hysteresis	Typ. 6%
Reverse polarity protection	Reverse polarity tolerant
Momentary current	0 - 1600 mA
Operating current	5 - 200 mA
Time delay before availability	<30 ms
Operating voltage indicator	LED, green
MTTF	1135 A
Diagnostic Coverage	0%
Ambient temperature	-25 to 70 DegC
Connection type	PVC cable , 2 m
Core cross-section	0.34 mm2
Housing material	Brass, nickel-plated
Sensing face	PBT
Degree of protection	IP67
