Pharma Stability Chamber

Product Details :

Specification

• Temperature Range          : 10°C to 60°C
• Temperature Accuracy     : ± 0.2°C
• Temperature Uniformity : ± 1°C
• Humidity Range                 : 40% Rh to 95% Rh
• Humidity Accuracy            : ± 2% Rh
• Humidity Uniformity         : ± 3% Rh

• Double walled with PUF insulation.
• TFT-touch screen 7’’ display PLC based controller
• SS 304 Interior & Exterior either SS 304 or Mild Steel
• UV lights get switched off automatically once the door is opened.
• You can test the samples on Fluorescent light or U .V lights separately as well as simultaneously.
• Uniform light distribution & high intensity levels allow quick response for forced degradation testing and confirmatory studies.
• Lights automatically shut off after a specified exposure level or time duration.
• Full-length inner glass door & metal door with gasket & lock on the outside
• Forced air circulation for uniform temperature
• PU wheels for easy movement
• Non condensing steam injection type humidity system with standby heater & auto switch overs
• CFC free cooling system consisting of hermetically sealed
• Stand by humidity system with booster humidification
• Complete Operations driven through PLC with data logging capacity of up to 1000 readings & email facility
• All operations through a single 7" Color Touch Screen
• High quality imported make T/Rh combo sensor with 4-20 mA output
• Safety devices: Low & high temperature cut-off settable thermostats & high humidity cut-off settable hygrostats
• Audio/Visual alarms for deviations
• Complete with DQ, IQ, OQ, PQ & SOP & Maintenance Manual
