Pharma Stability Chamber
Product Details :
Model Name/Number | WT 8 SC-S/G |
Capacity | 220 L |
Temperature Range | 10.0 deg C to 60.0 deg C |
Accuracy | 0.5 deg C |
Uniformity | +1 deg C |
Internal Size | 60 X 60 X 60 cm |
External Size | 80 X 110 X 125 cm |
Weight | 170 kg |
Power | 2500 Watt |
Specification
- Temperature Range : 10°C to 60°C
- Temperature Accuracy : ± 0.2°C
- Temperature Uniformity : ± 1°C
- Humidity Range : 40% Rh to 95% Rh
- Humidity Accuracy : ± 2% Rh
- Humidity Uniformity : ± 3% Rh
- Double walled with PUF insulation.
- TFT-touch screen 7’’ display PLC based controller
- SS 304 Interior & Exterior either SS 304 or Mild Steel
- UV lights get switched off automatically once the door is opened.
- You can test the samples on Fluorescent light or U .V lights separately as well as simultaneously.
- Uniform light distribution & high intensity levels allow quick response for forced degradation testing and confirmatory studies.
- Lights automatically shut off after a specified exposure level or time duration.
- Full-length inner glass door & metal door with gasket & lock on the outside
- Forced air circulation for uniform temperature
- PU wheels for easy movement
- Non condensing steam injection type humidity system with standby heater & auto switch overs
- CFC free cooling system consisting of hermetically sealed
- Stand by humidity system with booster humidification
- Complete Operations driven through PLC with data logging capacity of up to 1000 readings & email facility
- All operations through a single 7" Color Touch Screen
- High quality imported make T/Rh combo sensor with 4-20 mA output
- Safety devices: Low & high temperature cut-off settable thermostats & high humidity cut-off settable hygrostats
- Audio/Visual alarms for deviations
- Complete with DQ, IQ, OQ, PQ & SOP & Maintenance Manual
