Ice Plant Tutor (20 Kgs Capacity)

This Laboratory scale working model housed on a M.S. Angle frame further mounted on a wheels with instrumentation panel is used to determine) The working of ICE Plant ii) Co-efficient of performance (COP) and iii) Refrigeration circuit.

01. Hermitically Sealed Compressor
Make	: Tecumesh/Kirloskar
02. Air Cooled Condenser	: 12 x 13 x 2 row
03. Fan Motor :
a) Capacity	: 1/83 HP
b) Make	: AUE
04. Hand Shut Of Valves
a) Size	: ¼
05. Filter Drier
a) Make	: Danfoss
06. Energy Meters
Make	: Bentex/equivalent
07. Stirrer
a) Make	: Remi/Tullu
08. Pressure/ Compound Gauges
Range	: 0 to 300 psi/-30 Hg to +150psi
09. Brine Tank	: Stainless steel tank of 304 grade
10. Evaporator cooling coil	: 3/8 Copper with accumulator
11. Ice Cans	: GI / 4 Nos
12. Voltage stabilizer	: 2KVA
