I/P & P/I Converter Kit (combined setup)

Process Control Trainers

SPECIFICATION
The I to P and P to I Converter Trainer (52307) gives an idea regarding the operation of Electric to Pneumatic & Pneumatic to Electric conversion

Features
Compact Ergonomic Design.
User Friendly, Self Explanatory Systems.
Robust Construction.
Ms Powder coated frame.
Training Manual for Operation Ease

Experiments
Study of I/P & P/I Converter Setup
System Specifications
Digital Current Indicator with 3 ½ Digital Display
Current source with 3 ½ Digital Display
I/P Converter Input : 4-20 mA Output : 3-15 PSI
P/I Converter Input : 3-15 PSI Output : 4-20mA
Pressure Vessel Capacity 2.1 Kg/ cm2
Air Filter Regulator with Pressure Gauge

Services Required
Electric supply: 1φ230 V AC, 50 Hz.
Dry, Compressed, Clean Air supply at 2.1 Kg/cm².
