Hydraulic Remote-Controlled Jack
These Jacks are remote controlled type with detached hand operated pumping unit, Capacity 5 to 1000 Ton. These are superb in their design, practical, solid, reliable, compact, light weight and versatile performance with plain ram or screwed ram with safety lock nut arrangement. The jacks are provided with hand operated & motorized power packs..
Capacity in Ton | Ram Diameter | Total Extended Height | Hydraulic Lift | Closed Height | Piston Effective Area | Working Pressure Kg /cm2 |
5 | 36 | 370 | 150 | 220 | 10 | 640 |
10 | 46 | 370 | 150 | 220 | 16 | 640 |
15 | 58 | 380 | 150 | 230 | 26 | 640 |
25 | 70 | 390 | 150 | 240 | 38 | 640 |
50 | 107 | 420 | 150 | 270 | 90 | 640 |
100 | 140 | 440 | 150 | 290 | 154 | 640 |
150 | 175 | 450 | 150 | 300 | 240 | 640 |
200 | 205 | 465 | 145 | 320 | 330 | 640 |
250 | 225 | 485 | 145 | 340 | 398 | 640 |
300 | 245 | 495 | 145 | 350 | 472 | 640 |
400 | 285 | 500 | 140 | 360 | 638 | 640 |
500 | 315 | 510 | 140 | 370 | 780 | 640 |
750 | 390 | 530 | 140 | 390 | 1196 | 640 |
1000 | 450 | 540 | 140 | 400 | 1591 | 640 |
All Sizes in mm
