Horizontal Profile Projectors
Product Details:

Brand	Sipcon
Contour Illumination	24 V/150 W halogen lamp, illumination control with condenser unit provide light as per lens
Cooling System	Fan
Measuring System	D.R.O. / PC based Software
Optional Hardware	Profile Charts, Rotary Table, V-block, Center Holding Device Opto Edge Sensor, Rotary Encoder
Screen Size	300 mm
Light Axis	Horizontal
Optional Optics	25 X, 50 X, 100 X
Optics	10 X, 20 X (Std.)
Mount Optics	Turret Mount with Click Stop
Workstage Size	400 mm X 150 mm (Std.)
Measuring Range	150 mm X 100 mm (Std.)
Optional Measuring Range	X-Axis upto 350 mm, Y-Axis upto 200 mm
Focusing	75 mm
Linear Measurement	Built-in Glass Scale
Helix Range	+/- 12 Degree or +/- 15 Degree v
Projection Accuracy	+/- 0.05% (Contour / Surface)
Surface Illumination	Twin 24 V/150 W Halogen lamp provides shadowless light on optical axis
Stand	Unique rigid pedestal system facilitates vibration free handling of component
Voltage	110/220 V AC
Frequency	50/60 Hz
Motorized Movement	Optional (X, Y and focusing with speed control)
