Key features:

High sensitive digital camera:

The resolution of the monochrome CCD camera is 1.4 megapixel, which provides 16-bit imaging. The image resolution is up to 5 megapixel. The camera is sensitive enough to detect DNA/RNA, whose mass is less than 10 pg, identify the bands, that are very similar to each other and recognize the extremely weak signals form the fluorescence.

High transparent and low distortion lens:

The camera is integrated with high transparent and low distortion lens. The distortion rate is less than 1%, so that the camera is able to provide more sharp and clearer images.

Automatic operation system:

The operations on the instrument are controlled by the computer. For instance, the operation on the light lens, light source, UV protection, extracting bands, etc.

UV protection device:

The patented UV protection device protects the researchers from UV irradiation, while they have to extract or recover the gels.

USB port:

The captured images can be saved in the USB driver through the USB port automatically.

Application:

Nucleic acid detection

Ethidium Bromide, SYBR™GoldSYBR™Green

SYBR™SafeGelStar™FluoresceinTexas Red.

Protein detection

Coomaasie blue Silver Star Sypro™Red Sypro™OrangePro-Q Diamond Deep Purple™ etc.

Other applications

Hybridization membrane protein transfer film, dish colony counting, microtiterplates, TLC
