Furnace Gas Temperature-CDA
Product Details:

Rated Power (KW)	11 to 45 V d.c.
Brand	Land Ametek
Range	400 to 1800 DegreeC / 752 to 3272 DegreeF
Response Time	1 to 10 seconds adjustable
Ambient Temperature	5 to 50 DegreeC / 41 to 122 DegreeF
Sealing	To IP65 / NEMA4X requirements

GENERAL DESCRIPTION:The CDA thermometer is optimised to accurately measure the true gas temperature in boilers and incinerators using AMETEK Land’s unique non-contact infrared technology.
CDA measures the true temperature of hot flue gases and ignores interferences from ambient air and the furnace walls.Measures temperatures from 400 to 1800 °C / 752 to 3272 °F.
A versatile adjustable mounting assembly, complete with quick release adapter and air purge, provides ease of installation and removal for inspection purposes.
FEATURES & BENEFITS:
RESILIENT AND ACCURATE MEASUREMENT - Insensitive to the presence of gases other than hot carbon dioxide, CDA delivers a highly stable, true gas temperature.
MINIMAL MAINTENANCE REQUIRED-ensures no interaction with the combustion process and reduces maintenance requirements for the thermometer.
APPLICATIONS:
Waste Incinerators
Biomass Boilers
Coal Boilers
Industrial Processing
