Flow Control Trainer.

Flow control trainer is designed for understanding the basic principles of flow control. The process setup consists of supply water tank fitted with pump for water circulation. A DP transmitter is used for flow sensing which measures differential pressure across orifice meter. The process parameter (flow) is controlled by microprocessor based digital indicating controller which manipulates pneumatic control valve through I/P converter. The control valve is fitted in water flow line. These units along with necessary piping are fitted on support housing designed for tabletop mounting. The controller can be connected to computer through ethernet port for monitoring the process in SCADA mode.

Features:

• ON-Off & PID operation
• Auto tuning
• SCADA study
• MODBUS communication
• Multi drop and point to point Communication
• Server-Client communication

Range of experiments:

• Study of open loop (Manual control)
• Study of on/off controller
• Study of proportional controller
• Study of prop. integral controller
• Study of prop. derivative controller
• Study of PID controller
• Study of stability of the system (Bode plot)
• Study of multi drop communication
• Study of Server-Client communication

Utilities required:

• Electric supply: 230 /- 10 VAC, 50 Hz, 1 phase
• Water supply: Distilled water @10 liters
• Computer: With standard configuration
• Air Supply: Clean, oil and moisture free air,
• Support table: Size: 800Wx800Dx750H in mm.
