OPTICAL SYSTEM

• Principle Absorption spectrometry

• Range of measurement From -0.1 to 3.4A

• Normal Spectral range Automatic via filter wheel

• Filters 405, 450, 492, 630 nm.  4 extra position

• Bandwidth 10nm (±2 nm)

• Reading error 2% at 2.5 A

• Light source LED

• Zero Automatic

• Settings Monochromatic & Bichromatic readings.

• Detector Schottkey type photodiode - Silicon


STRIP TYPE

• Single strip of 8 wells at a time


PRINTER

• Type Fast Thermal Graphic

• Printing speed 50 mm/sec

• Dots per line 384 dots/line

• Paper Thermo sensitive, 57 mm wide

• Easy paper loading


DATA OUTPUT

• Connection Type RS-232: p pin D type connector


SCREEN AND KEYBOARD

• LCD blue LED back lit 240 x 64 pixels.

• Keyboard Tactile Soft-touch
