Waveform Synthesizer Cum Analyzer
Product Details:
Waveform  Synthesiser Cum Analyzer ( Fourier  Concept  Demonstrator )
In communication one always comes across signals which are non sinusoidal and complex. Fourier analysis tells us that any complex signal consists of fundamental and a set of even and odd harmonics.
Synthesis of waveform:
Done by selecting 16 points on waveform
Slide Pots : 16, for selecting shape of waveform,
Knobs set to form pattern
resemblling waveform
Magn. Spectrum : Can be plotted.
