Red Line Generating Laser
Product Details:
Technical specification :

Type Of Light	Beam Light
Wattage	100MW
Lighting Type	LASER LINE BEAM
Lighting Color	RED/GREEN/BLUE
Body Material	Metal
Brand	ADLABS INSTRUMENTS
Emitting Color	Red, Blue, Green
Input Voltage V	5VDC

Wavelength : 650nm
Output Power : 100 mW
Output Mode : Continuous
Input Voltage : 3VDC /  5 VDC / 12VDC / 24VDC  (operating voltage avilable in all range )
Operation Current : < 300mA
Divergence : 0.6 to 1.2mrad
Line Width: 1mm at 1 Meter (depans upon buyers)
Bent Rate   : < 1m @5Meter
Expected Lifetime : > 6000 hours
Operating Temperature Range : -100C to +50 0C
Storage Temperature Range : -400C to +85 0C
Warranty period : 1 year
The products are widely used in the field of
Military Positioning Equipment, Laser medical equipment, Laser marking, Cloth cutting , wood cutting Industries , tyre Industries ,  Power Tools,  cutting marking, Mechnical Positioning  and so on.
The products are in high stability, reliability, and consistency with long service life.
