Function Generators
Product Details:
Model 800 range of Function Generators are low cost instruments for the customer looking for the best price-performance ratio. All the models introduced by us offer high quality sine, square and triangle waveforms with DC off set, sweep frequency, VCO facility, frequency modulation, TTL trigger output, push button selection of ranges, digital display of frequency and multiturn frequency control.The specifications are as given below:
Frequency Range : a) Model 800 / 100K : 0.1Hz to 100 KHz.
b) Model 800 / 1M : 1 Hz to 1 MHz.
c) Model 800 / 2M : 2 Hz to 2 MHz.
d) Model 800 / 3M : 3 Hz to 3 MHz.
e) Model 800 / 5M: 5 Hz to 5 MHz
f) Model 800 / 10M: 10Hz to 10 Mhz
Waveforms : Sine, Square and Triangle.
Output Magnitude : 0-20 V P-P, variable.
Trigger Output : TTL output given.
VCO/FM/Sweep : Facility provided.
Display : 3½ Digit LED/LCD digital display of frequency.
