Personal Noise Dosimeter
PRODUCT DETAILS

Accuracy	1.0 dB
Display	Digital
Measuring Range	120dB
Power Supply	230V
Calibration	Manual
Resolution	0.1 dB

The Edge 5 is an intrinsically safe, small, lightweight, data-logging noise dosimeter that provides real-time personal noise exposure readings. The Edge 5 carries approvals from ATEX, IECeX, and MSHA for use in volatile environments and features three independent dosimeter readings, eliminating the need for multiple studies. Designed to be user-friendly and intuitive, this noise dosimeter is an excellent solution for personal noise exposure monitoring in a variety of workplace environments.
INDUSTRY APPLICATIONS

• Mining
• Oil and Gas and Downstream Refineries

• Commercial Construction
• Road Construction

• Military
• Industrial Manufacturing


KITS INCLUDE

• Extra wind screen
• Calibrator microphone adapter

• Hard plastic carrying case
• Quick start guide
• Product manual on USB


*Additional kit options include docking station and AC-300 calibrator
SPECIFICATIONS

• Battery life - 40 hours nominal without LED activated
• Microphone - 1/4 inch prepolarized condenser (electret) field replaceable threaded microphone

• Dosimeter -  eg5 has three independent dosimeters. The third dosimeter is enabled through Detection Management Software.
• Convenient Presets  Preprogrammed to OSHA and ACGIH standards.

• Frequency weighting A, C, Z
• Independent Exchange Rates - 3 dB, 4 dB or 5 dB


Additional Information:

• Production Capacity: 10
• Delivery Time: 6-8 weeks

• Packaging Details: Export
