Ozone Monitor & Controller
Product Details:
Featuring accuracy and ease of use and installation, this ozone monitor system is an excellent device for hospital and industrial applications. This ozone monitor detects real time ambiance ozone gas level and also detects temperature and humidity at the same time. This unit is wall mounted and features LSC display that displays ozone, temperature and humidity and also controlled device status etc. The LCD and front-panel controls make setup and operation easy.
Features | |
Wall mounted system | LCD displays ozone, humidity and temperature |
Controls on front panel | High sensitive ozone gas sensor |
RS-485 communication interface | 15KV antistatic protection |
| Specifications | |||
| Model | PX-201 | ||
| Ozone measuring range | 0.01 ~ 1ppm (10ppb ~ 1000ppb) | ||
| Temp. measuring range/setting range | 0 ~ 50°C / 5 ~ 45°C | ||
| Humidity measuring range/setting range | 0~99%RH / 5~95%RH | ||
| Sensor Type | Japanese semiconductor gas sensor | ||
| Lifetime of Sensor | 5 years | ||
| Temperature Sensor | NTC | ||
| Humidity Sensor | HS series capacitive sensor | ||
| Warm up time | 1 hour | ||
| Power | 24VAC, 24VDC, 220VAC, 110VAC | ||
| Analog output | 0~10VDC linear output (10 Bit) | ||
| Relay output | 2A (220VAC/30VDC) | ||
| Communication interface | RS485, 15KV antistatic protection | ||
