TECHNICAL DETAILS

• Feeding Head Float balanced gravity flow filling system

• Production Speed 50 - 52 / 100 - 104 pouches / min

• machine Control System Solid state control system

• Packing Range 100 - 500 ml

• Film Width upto 225 - 325 mm

• Film thickness 65 - 85 microns

• Film Material Co-Extruded virgin films

• Sealer heating System Continuous Only

• Filling Accuracy + / - 1- 3 ml

• Inner Core Dia. of Film Roll 70 mm

• Outer Core Dia. of Film Roll upto 350 mm

• Pouch Style Center sealed Pillow type

• Pouch Width upto 100 -150 mm

• Pouch Length Upto 160 mm

• Power Consumption 1.2 & 2.4 kW/ Hour

• Peak Power 2.5 & 5 KW

• Power Requirement 1 Phase, 220 V, 50 Hz

• Cooling Water Requirement No Cooling Water requires

• Pouch Counter Provided

• Date printing Device Optional

• Machine Dimensions 1700(H) x 800(W) x 1200(Depth) mm

• Net Weight 350 7 650 Kg's (approx.)
