Environmental Test Chambers
Product Details:
Special Features

• Suitable for conducting various quality control tests under controlled conditions of temperature and humidity.
• Excellent quality of magnetic glue packing for external doors.

• User oriented design of shelves lets you adjust each space of the shelves without difficulty.
• The inner chamber is made of stainless steel (S.S.-304 grade) and the outer wall of the light steel sheet is painted and the caster is mounted on the wheel.

• High grade polyurethane foam (PUF) insulation between the outer and inner chamber for minimum thermal damage.
• Front double wall lock is provided with lock and arrangement.

• A self-cooled air circulation fan is applied to maintain uniform temperature and humidity conditions throughout the room.
• Humidity is created through the steam production tank on the base / top.

• Cooling temperature was provided with refrigeration system to control temperature above 50C to 600C + 10C and humidity from 5% to 40% to 95% RH + 3% RH.
• CFC free ECO fully compressor.


Applications

• Test houses and research.
• Automotive industry

• Electronics industry
• Aviation and space industries

• Plastic processing industries
• Clothing industry, manufactures of sports articles

• Chemical industry
• Paints and coatings

• Agricultural research
• Bio related

• MODEL No.	RSI/EC-112	RSI/EC-145	RSI/EC-171	RSI/EC-224	RSI/EC-280	RSI/EC-340
  Capacity	112 ltrs	145 ltrs	171 ltrs	224 ltrs	280 ltrs	340 ltrs
  Volume	4 Cuft	5 Cuft	6.1 Cuft	8 Cuft	10.0 Cuft	12.0 Cuft
  No. of Perforated Trays	2	2	2	2	3	3
  MOC Outer	Powder coated CRC Steel Sheet or Stainless Steel.
  MOC Inner	Chamber and trays made of Stainless Steel (SS-304)
  Type	Forced Convection Type
  Temperature Range	5OC to 60OC

•
