Chamber

SS 3l6 for corrosion and gas resistant. The inner surface is smoothly finished
to minimize gas deposit.

 Mode of Heating

Chamber will be heated with Strip air heater / Hot water circulated through the
lump id coil of SS 304 around the chamber to maintain the chamber temp. at 35-55°C.

 lnsullation of Shell

50mm thik R. B. fibre glass covered with SS 304 outercover.

 Door

Single, SS 316, hinged type with quick release locking arrangement with suitable
safety interlocking so that the process cannot start unless the door is properly closed and cannot be opened during the process.

 Paneling

SS 304, Box type design, MMI-PLC will be located within the panel.

 Vacuum Pump

Diaphragm vacuum pump provided to achieve high level of air removal for high sterility
and efficient residual gas removal during aeration process from the chamber and gas strap to separate and evacuate the gas. lnbuilt Gas catalytic converter for the exhausted ETO gas.

 Gas Purging

Provided with cartridge punchering system as well as provision for EO + C02 cylinder.

 Sterilization
Process

Fully automatic PLC / Touch Screen models. Two nos. sterilization cycles with
inbuilt leak test and aeration will be provided, which will be completed automatically.

 Stand

SS 304

 Documentation

Thermal Printer / Dot – matrix printer which will print date, batch/load number,
program type selected and program parameters which includes one point
temperature print out.

 Programs

Following programs with variable parameters are provided to take care of user’s
requirement. Fully automatic operation.

 Cycle
Description

Sr. No.

Inner Dimension (in MM)

Capacity(in ltr)

In CFT

1

                300X300X600

54

1.9

2

300x300x900

81

2.8

3

300x300x1200

108

3.8

4

320x320x1350

138

4.8

5

350x350x1200

150

5.2
