Digital PH Controllers

Product Details:

Usage/Application	Industrial
Brand	Applied Techno System
Current	1 A
Accuracy	+/- 2%
Digit Display Size	Single Display
Color	Black
Material	ABS Plastic
Country of Origin	Made in India
Tempreture Range	-10 to 110 Degree C

Digital pH Controllers is easy with the Alpha pH 190 limit controllers. Featuring 6 sub-menus accessible via a four-button keypad for quick, easy setup and calibration, the controller/transmitters also come with two levels of password to protect against unauthorised tampering.For faster and more convenient control, choose the Alpha pH 190 which allows direct access to the set-point adjustment and calibration menus.
Features:

• Easy push-button calibration with USA/NIST buffer recognition for fast, effortless calibration. Controller freezes data transmission and relay activities during calibration and maintenance

• Symmetrical mode of operation for clear, uninterrupted readings even in electronically noisy environments

• Two SPDT relays with independent hysteresis – effective high/low set-points limit control with minimal relay-chattering

• Choice of automatic or manual temperature compensation. Three-wire system compensates error due to cable resistance

• 85 to 250 VAC. 50/60 Hz or DC variable input allows controller to be used with a wide range of supply voltages

• Full-scale 4 to 20 mA galvanically isolated current

• Ooutput for process control

Specification:

• Range 0.00 to 14.00 pH

• Resolution 0.01 pH

• Accuracy ±0.01 pH

• ORP Range -999 to 1000 mV

• Resolution 1 mV

• Accuracy ±2 mV

• Temperature

• Range -10 to 110 ºC

• Resolution 0.1 ºC

• Accuracy ±0.5 ºC

• Sensor Pt100; 2 or 3 wire

• Compensation Auto/manual (0 to 100 ºC)

Set Point And Controller Functions:

• Set point 1 (SP1)/

• Set point 2 (SP2) 0.00 to 14.00 pH or -999 to 1000 mV

• Switching pH Hysteresis 0.00 to 2.00 pH

• Switching ORP Hysteresis 0 to 300 mV

• Function Limit control

• Contact Outputs 2 SPDT relays
