Digital Online Dew Point Meter
Product Details:

Usage/Application	Industrial
Brand	Applied Techno Systems
Operating Temperature	0 -80 deg C
Accuracy	+/- 2%
Moisture Range	0-23000 PPM
Material	MS
Display Type	LCD Display
Country of Origin	Made in India

Application:

• Compressed Air
• Industrial Process Control

• Drying system
• Protection systems

• Glove box
• Turbines
• HVAC
• Breathing air


Specification:

• Probe: Capacitive Thin film water vapor sensor
• Parameters (selectable) :Dew point, Moisture , Humidity,Vapor Pressure, Temperature

• Range: Dew Point : -60 to + 30 deg C( other Ranges are Optional)
• Moisture : 0- 23000 PPM

• Humidity : 0-100%
• Vapor pressure : 0-17.5mm Hg

• Temperature : 0-80 deg C
• Dew Point Accuracy : +/-1 deg C from 0 deg C to 30 deg C dew point, +/-2 deg C from  -60 deg C to 0 deg C

• Analog output:  4-20 mA
• Resolution: 0.1
• Max Sample Temp: 80 deg C

• Max Pressure: 12kg/cm2
• Response Time: 10 sec  for 63% step change

• Display Type: Alphanumeric LCD / 31/2 Digit LED ( Optional)
• Housing : High Impact plastic
• Power: 220V/50Hz,110 V/50Hz optional

• Output relay: 5AMP,220 volts rating
• Dimension: 254 x180x 90 mm

• Additional Features
• Computer Interface: Rs-232
