Digital IC Trainer
Product Details:
Usage | Laboratory |
Brand | Mars |
Model | ME 511 |
Clock | 1Hz, 100Hz & 1KHz |
Logic Inputs | 10 Nos. logic '0' & logic '1' ( Through Switches ) |
Output Voltages | 5VDC |
Output indicators | 10 Nos.
|
Objective : To verify the truth tables of Basic Logic Gate,Combinational Logic Circuits & Sequential Logic Circuit
Other Details:
Housed in PVC cabinet , symbol diagram printed, Connections of various IC’s/ components ( NAND Gates, NOR Gates, OR Gates, AND Gates , EX-OR Gates (4 each), NOT Gates ( 6 No’s), JK Flip Flop
(2 No’s) RS Flip Flop, D Flip Flop (1 No. each ), all important outputs & test points brought at glass Epoxy front panel.
Also provided with patch chords & instruction manual
