Dew Point Transmitter
Product Details:
Since our inception, we are instrumental in offering premium quality Dew Point Transmitter. This transmitter is designed as compact, simple and reliable instruments, which will continually monitor air dryer performance, compressed air quality and dry gas moisture, from ambient dew point levels to as low as -110ºC to 20ºC. Besides being manufactured from best-grade raw-material and advanced technology, the offered transmitter is inspected properly by our deft professionals. Owing to features like high efficiency and sturdiness, the offered transmitter is exceptionally valued by our precious clients. The offered transmitter is available with us in various sizes and other related specifications at affordable price.
Features:

• Smooth performance
• Precisely design
• Long service life


Other Details:

• Thin Film Capacitive Sensor Technology
• Multiple Housing Configurations

• Very Low Drift
• Long Sensor Life

• Robust Reliably Construction for Industrial Applications
• Samples Pressure Upto 12 Kg/C2M
• Inbuilt Thin film Capacitive sensor


Application:

• Monitoring Control of Air Dryers
• Plastic Dryers

• Natural Gas Processing, Transportation Distribution
• Glove Boxes
• Welding Gases


 Specification:

Principle	Thin Film Capacitive
Range	Degree C, PPM % RH
Resolution	0.1 Unit or 1 Unit (Application based)
Sampling Method	Direct Plug In
Display	Alphanumeric LCD
Power Source	24VDC or 230VAC
Accuracy	/2%
Response Time	<5 Second
Data Storage	5000 or 10000
Analog Output	4-20mA
Sensor Life	2-3 Years
Operating Time	continious
Environmental	ambient
Temperature	15degree Celsius
Humidity	< 85%RH
Atmosphere Pressure	86- 106Kpa
Housing	High Impact Plastic
Dimension in mm	120 (W) X 125(H) X 1120(D)
Weight	1.5 KG
Warranty	One Year
