Cylinder High Pressure Gas Regulator
Product Details:

Minimum Order Quantity	1 Piece
Warranty	12 MONTHS
Inner Diameter	40 MM
Automation Grade	Manual
Maximum Inlet Pressure	210 BAR
Product Code	SEE-2SPR-01
Grade	A1
Outlet Gauge	16 BAR
Gas	NITROGEN,HYDROGEN,AIR,HELIUM,OXYGEN,ARGON,CO2,N2O,ACETYLENE,HCL,AMMONIA,CHLORINE,H2S
Display Type	ANALOG
Color	Silvery White
Quantity Per Pack	1 NOS
Flame Resistant	YES
Inlet Pressure	210 BAR
Part Number	SEE-2SPR-01
Display	ANALOG
Product Type	REGULATOR
Model Name/Number	SEE-2SPR-01
Design Pressure	210 BAR
Material	Stainless Steel
Maximum Delivery Pressure	16 BAR
Flow Capacity	250 LPM
Rated Flow	0.6
Pressure	150 BAR
Phase	NA
Regulator Type	High Pressure Regulator
Weather Resistant	NON-CORROSIVE
Brand	SAMPHIRE
Outlet Diameter	52 MM
Flow Range	250 LPM
Media	GAS
Leak Proof	YES
Country of Origin	Made in India
Weight	3 KG
Usage/Application	Industrial
Size	52 MM DIA
Cga Inlet	5/8" BSP MALE
With Tube	No
Pattern	AS PER OUR OWN PATTERN
Capacity	500
Pre Heater	NA
Wall Thickness	8 MM
Packaging Type	STANDARD
I Deal In	New Only
Finishing Type	MATT

With a focus on the ever-evolving demands of our customers, we have come up with a wide range of uniquely designed Two Stage Pressure Regulator. Our skilled professionals use premium grade components and contemporary technology in the manufacturing process of this regulator. To ensure its functioning and dimension accuracy, this regulator is duly examined against numerous measures of quality in accordance with defined industry standards. With a focus on the ever-evolving demands of our customers, we have come up with a wide range of uniquely designed Two Stage Pressure Regulator. Our skilled professionals use premium grade components and contemporary technology in the manufacturing process of this regulator. To ensure its functioning and dimension accuracy, this regulator is duly examined against numerous measures of quality in accordance with defined industry standards.
Features:

• Stainless Steel Diaphragm
• Standard 10 μm sintered bronze filter at inlet of main valve assembly

• Cleaned for Oxygen service
  Specifications:
• Stainless Steel Diaphragm

• Standard 10 μm sintered bronze filter at inlet of main valve assembly
• 1.6 μm internal surface finish as standard

• Cleaned for Oxygen service
• Bubble tight shut-off

• Inlet pressure: 210 bar (3000 psi)
• Outlet range: 0 to 16 bar (360 psi)

• Supply pressure effect less than 0.05%
• Samphire manufacturers various kinds of Regulators. Samphire Regulators have been designed to meet the demand of High Purity Corrosion Resistance Product Specially Suited for low level PPM Moisture Two types of Cylinder Regulators available Brass Chrome Plated body with SS diaphragm and SS body with SS diaphragm. Regulator consists of inlet & outlet pressure gauges. Inlet pressure gauge shows the total pressure of cylinder and outlet pressure gauge shows regulated pressure.
