- The Bath is double walled inner working chamber is made of Stainless Steel & outer case is made of Mild steel finished in epoxy powder coating paint. Space of 50mm between inner & outer wall of the bath is insulated with puff. The lid of the Bath is insulated double walled fixed with hinges and has locking arrangement. The bath is mounted on castors.
- Two sealed compressor, fan cooled condenser & all its accessories are placed at the lower portion exactly below the bath.
- Temperature is controlled by Microprocessed Electronic Digital Controller Cum Indicator form 5 °C to ambient temperature with accuracy of +\ - 0.2 °C .
- Control panel is given on right hand side of the bath having the Rotary switch to operate the bath. ON –OFF Switch, Voltmeter, 2 Nos. indicators with Heavy Duty Circulating Pump Motor to circulate chilled water to your external machine to work on 220/230 volts A.C.
- Large Dimensions Chiller can be manufactured as per customer's requirement and rates shall be given on request.
Constant Temperature Refrigerated Liquid Bath Chiller
- Views: 495
-
Narang Scientific Works Pvt Ltd - Product Code: NSW0000016
- Availability: In Stock
- ₹0
