Specifications:

• Laboratoty Pulverizer is a disc type grinder, designed to grind virtually any material to produce a fine mesh sample in one operation.
• It is a self contained grinder, with a rotary disc, having a planetary movement in a vertical plane.
• This feature gives added life to the moving parts and produces a sample of uniform fineness.
• Grinding is done between two discs, one of which is stationary and the other revolving eccentrically at high speed.
• The discs are made from heat treated mechanite metal. With the help of a convenient hand wheel, the six of the final product can be adjusted.
• This can be done, even while the machine is in operation.
• A self locking device holds the hinged grinding chamber in place and affords easy and quick access to it, for removal of ground samples & for cleaning.
• The Pulverizer has a capacity of reducing about half a kilogram of Quartz type sample to 100 mesh in about minute.
• The Pulverizer is supplied complete with a 3 H.P. Motor, a starter, “V” Belt pulley drive and mounting wired for 440 Volts, 3 phase A.C. 50 Hz.
• Disc Diameter : 175 mm.
• Maximum feed Size : 6 mm
• Yield : 250 gms/min
• size of finished product. : 100 mesh
