Unconfined Compression Test Apparatus

Product details :

About Product :

Determination of soil shear strength is essential for designing the foundation of structures, soil and soil retaining structures, soil slopes, etc., Shear strength of soil depends on various factors and in situ soil conditions. Therefore, when laboratory tests in the soil are performed to evaluate the shear strength of soil, the in situ soil conditions and other factors should be simulated for obtaining meaningful results. For example, the Unconsolidated Undrained test on soil will yield the undrained strength, which can be used for finding the immediate stability of an excavation, whereas a consolidated undrained test with measurement of pore pressure can be used to evaluate the effective strength parameters of soil for designing the long term stability of an earth-fill dam. It is well known that the engineering behaviour of soil depends on the effective stress and not the total stress. The effective stress can be calculated by measuring the total stress and subtracting the pore water pressure from it. To cater to the needs of shear strength determination of soil we have a range of equipment.

Specification :

• Lift Plate Journey Per Revolution of The: 0.2mm
• Lifting Speed: 1.8mm/Min±15%
• Diameter of The Remolding Cylinder: Φ39.1mm
• Transport Package: Export Wooden Case
• Type: Unconfined Compression Testing Machine
• Max. Stroke of The Lift Plate: 30mm
• Max. Axial Load: 0.6kn

Features :

• Capacity : 50kN
• Material : Stainless Steel
• Type : Manual
• Minimum Order : 01 Piece
• Other Details
• Item Code : VSLIC-S215
• Packaging Details : Standarad Packaging
• Delivery time : Within 1 week or Depends upon Distance

Additional Information:

• Item Code: VSLIC-S215
• Delivery Time: 1 Week or Depend on the Distance
