ELECTRICAL OPERATED COMPRESSION TESTING MACHINE WITH FLEXURE MACHINE

Product Details

It is supplied with a pressure gauge calibrate with NCCBM certified proving ring. It is available in Channel Model. It consists of a Loading unit & a motorized pumping unit. Separately Loading unit for Flexure testing of Beam Mould 15x15x70cm or 10x10x50cm is also provided, A copper connecting tube is attached with both loading unit, capable of bearing high pressure connects the pumping unit to the jack. The testing machine is equipped with a junction box that connects the push-button starter and the motor. Pressure Gauge 0-2000KN, 0-100 KN, is fitted at an angle for easy readability. Micron switch shall switch off the motor automatically as the load reaches the rated capacity of the machine. Relay is incorporated, in case of power brake down, the motor shall stop & would not start unless push button is operated. It is nicely spray painted. It also operated by hand in case of electricity is not available.

• Also available in 4 or 2 Pillar model.
