Coating Thickness Meter
Product Details:
Brand | Source 1 |
Model Name / Number | Indi 6156 |
Type | F / NF |
Measuring Range | 0 to 1000 um |
Accuracy | 2.5 um |
Resolution | 0.1 um |
Our customers can avail an unparalleled range of Coating Thickness Meters from us. The offered range of coating thickness meters is made utilizing high grade raw material and innovative techniques in strict compliance with the international quality norms and standards.
Along with this, the offered range of coating thickness meters is utilized in different industries mentioned below
- Petroleum
- Shipbuilding
- Power station
- Machine manufacturing
- Coating Thickness Meter (Non Magnetic Materials)
Specifications : | |
Display | 4 Digit 10mm LCD |
Thickness Range | 0 – 1000 Microns / 0 – 40 mil (Switch Selectable) |
Accuracy (Resolution) | ±1~3%n or 2.5um (0.1(<100 Micron) / 1 (>100 Micron) |
Sensor Type | Integrated Eddy Current / Magnetic Probe (Auto / Manual Selectable) |
Material Selection | Auto / Manual |
Min Base Thickness | 0.3mm |
Min. Measuring Area | 6 mm Dia. |
Min Radius | 3mm Convex / 50mm Concave |
PC Interface | RS 232 Output Provided (Cable & Software Optional) |
Accessories | Carrying case, Two base block, Calibration Foil set |
Power Off | Auto / Manual |
Aux. Supply: | 4 x 1.5V AAA Size Battery |
Cabinet Size | 125 X 69 X 25mm ABS Plastic |
Additional Information:
Item Code: Model-indi-6152
Coating Thickness Meter
- Views: 89
- Vendor: Source1 Instruments
- Vendor Type: Manufacturer, Supplier
- Product Code: MNA0000027
- Availability: In Stock
