Capacitance Level Transmitter
Product Details:

Local Display	8 x 1 LCD
Power Consumption	24 V DC, External
Material	SS 316 with Teflon coating
Process Temperature	250 deg C max
Accuracy	2% of full flow
Linearity	(+/-) 2 % of F. S.
Type of Output	4 to 20 mA DC, 2 wire
Response Time	Smaller than 6 VA
Temperature Coefficient	Smaller than 1000 m Sec

A Capacitance Level Transmitter is formed between the probe and the vessel wall and the level of the measuring medium rises or falls, a capacitance between the probe and vessel wall changes proportionately in the right manner. Our prestigious clients & customers can avail from us a wide range of Capacitance Level Transmitter from us.

Details:
Flowstar Series FECTX-100 are capacitance type level transmitters. The probe is based on properties of the capacitor. Vessel wall & probe forms two electrodes. If the vessel is of nonconductive material, the probe will be the double-rod type. The distance between electrode & surface area of electrodes remains unchanged. The variable is the depth of the material being measured which represents the dielectric constant between the two electrodes. Air & vacuum have a relative dielectric constant as 1 & that of liquids, it is greater than 1. The capacitance of the capacitor the, therefore, depends on how much material lies between the probe & vessel wall i.e. whether the probe is covered with or free from the material. The capacitor changes with a change in the level of the material & provide corresponding 4-20 mA DC continuous output
Salient Features:
2 wire system
Continuous 4-20 mA DC output
Simple low cost & reliable
Trouble free operation for conductive /nonconductive
Liquids, slurries
Flameproof IP-65, P-65, IIA IIB, CMRI Certificate housing
