CNC Milling Machine (3-Axis)

Travel

• X-axis travel : 700mm
• Y-axis travel : 400mm
• Z-axis travel : 330mm
• Distance from table surface to spindle gauge plane : 150 to 480mm

Table

• Table working space : 850 X 410mm
• Table loading capacity : 300 kg
• Table surface configuration : 3T-slots, size 14mm Pitch 125 mm

Spindle

• Spindle speed range : 100-10000min-1
• Type of spindle taper hole : 7/24 taper No.30
• (with air blow)

Feedrate

• Rapid traverse rate : 48m/min (X,Y,Z)
• Feedrate : 1 to 30,000mm/min
• High Speed, High Precision and Ultimate Efficiency
• NANO CNC System has a ultra-precision pulse coder for control with interpolation and feedback in nanometers.
• High acceleration positioning with maximum acceleration of over 1.3G.
• Rigid structure of machine mechanism for high precision machining at high efficiency.
• AI contour control I & HRV control which greatly reduces profile errors caused by servo delays.
• AI Contour Control II (200 blocks).
• User manual
• Technical manual
• Operating manual
• Related drawing
• Related inspection/quality/calibration certificate
• Maintenance software in softcopy
