Boiling Heat Transfer Unit

01. Glass Tube
a. Diameter	:100mm OD (Approx.)
b. Height	:275mm (Approx.)
02. Copper Tube
a. Diameter	:9mm OD (Approx.)
b. Material	:150mm (Approx.)
03. Measuring Instruments
a. Digital Voltmeter Range	:0 to 300 V
b. Digital Ammeter & Range	:0 to 5 Amps
c. Digital Temperature Indicator with Selector switch
Range	:Ambient to 199.9 Deg. c
04. Thermocouples
a. Type	:Cr. AI
b. Length	:1 Mt.
05. Dimmer
a. Make	:Agro/Equivalent
b. Range	:0 to 10 Amps
06. Pump
a. Make	:UP National Mfg. Co., Equivalent
b. Model	:Tullu 60
07. Rotameter
a. Material	:Acrylic
b. Range	:40 to 60 cc/sec
08. Sump Tank
a. Size	:200 x 200x 400mm )Approx.)
b. Materail	:S.S
