Benkelman Beam Apparatus
Product Details:

Color

Natural

Voltage

110V

Capacity

20L/Hr

Power

100-200W

Driven Type

Electric

Temperature Range

0-5 Deg C, 10-20 Deg C

Warranty

1 Year

Automation Grade

Automatic

Ambient

0-180 Deg C 180-360 Deg C

The Benkelman Beam Apparatus is generally used for pavement analysis. The principle of our Benkelman Beam Apparatus is that a long beam is laid on a road surface at one end and balanced at a point to provide it a ratio of 2:1 that will magnify small refractions triggered by loadings adjacent to the end of the beam in connection with the road. With this, the small movement can be measured precisely by utilizing a highly stable platform adjacent to the other end of the beam.

Special Features

• Light weight construction that can be separated into two parts for ease of transport.
• Supplied with dial gauge 0.01 x 25mm.

• Compact, unique and possesses a telescopic design.
