Driven Type

Electric

Automation Grade

Automatic

Output

25 - 30 [ DEPENDING UPON MATERIAL PROPERTY ] 50 - 60 [ DEPENDING UPON MATERIAL PROPERTY ]

Filling Range

5 GM TO 1 KG [ WITH THE HELP OF REQUIRED CHANGE PART ].

Electrical Supply

1.5 HP , 220 / 415 V , 50 HZ [FOUR WIRE ]

Power

220 / 440 V , 50 HZ [FOUR WIRE ]

MODEL

NPAPFCS – 40

NPAPFCS – 70

OUTPUT (BPM)

25 – 30 [ DEPENDING UPON
MATERIAL PROPERTY ]

50 – 60 [ DEPENDING UPON
MATERIAL PROPERTY ]

HOPPER CAPACITY

25 LTR

ACCURACY

± 1 %

POWER

220 / 440 V , 50 HZ [FOUR WIRE ]

ELECTRIC MOTOR

1.5 HP , 220 / 415 V , 50 HZ [FOUR WIRE ]

CONVEYOR HEIGHT

850 MM TO 950 MM ADJUSTIBLE

BOTTLE SIZE

Ø 22 MM TO Ø 100 MM , MAXIMUM HEIGHT 210 MM

FILLING SIZE

5 GM TO 1 KG [ WITH THE HELP OF REQUIRED CHANGE PART ]

CAP SIZE

19 MM TO 80 MM MAXIMUM, WITH THE HELP OF CHANGE PART OVERALL DIMENSION.
