VERTICAL AUTOCLAVE

Product Details :

Applications

“RELICLAVE” is the most Reliable Autoclave for all applications requiring, total destruction of all living micro-organisms, in laboratories, hospitals, nursing homes, R & D labs. etc. It is used to sterilize equipment  by subjecting them to high pressure saturated steam at 121º C for around 15–20 minutes.

Construction

• The outer chamber is made of heavy gauge MS Sheet, treated for degreasing and rust proofing & duly powder coated for VAPO Series (OR) lined with heavy gauge SS Sheet for SLIN Series.
• The inner chamber is made of thick 304 Grade Stainless Steel Sheet.
• Lid made of thick machined high grade Stainless Steel plate.
• The unit has Radial Locking arrangement duly chrome plated with paddle lifting mechanism.
• Unit is provided with Spring Loaded Safety Valve, Pressure Gauge, Pressure Release Valve, Water Level Indicator & Drain Valve.
• Unit is hydraulically tested to withstand upto 40 psi pressure.
• All internal joints are Argon arc welded, ground and polished to give crevice free internals.
• Molded joint-less Silicon Rubber Gasket is provided for leak proofing.
• The unit is electrically heated by flange type/immersion type heaters.
• Supplied with Control Box fitted with Mains & Heating Indicators, ON / OFF Switch, Cord & Plug to work on 220/230V, 50Hz AC supply.

Optional Accessories :

• Automatic Pressure Control Switch

• Automatic Low Water Cut-off Device
• Digital Temp. Indicator cum controller.
• Timer with Alarm System
