Parameter

SPECIFICATION

Chamber

Chamber Size

500mm(dia)x900mm(dept)  185 ltr

Material

SS316L with full Argon welding

Thickness

4mm

Internal

Mirror Finished

Design Temperature

134°C

Vacuum

Full

Operating Pressure

2.2 KG/ CM2

HYDROTEST PRESSURE

5 KG/ CM 2

All Piping and

Connection to Chamber

All process piping in contact with the chamber-SS316L

All connections and fittings used are sanitary tri-clamp with silicone seals.

All non-contact piping is fabricated from SS 304

All connections used are threaded.

The pipelines also have a 2% slope for full draining to prevent contamination.

Pressure Guage (SS)

1 nos SS304 gauge provided
