HORIZONTAL AUTOCLAVE

The Autoclave is mounted on MS tubular stand.The chamber, jacket and boiler made of Stainless Steel. Outer Shelf is also made of Stainless Sheet. Hinged door is made of Stainless Steel plate.Radial locking Arms, prevent opening of the door while steam is inside the chamber. Steam is generated in a separate boiler which is placed below the main body.The Steam generator is fitted with easily replaceable heaters & water level indicator.Autoclave hold pressure at selected point between 10 to 17 psi +/ -3 psi		Horizantal Autoclave(Cylindrical)
Hydraulically tested at 40 psi.pressure control through single point multiport valve fitted on the top of the autoclave.
1. Radial Locking	Horizantal Autoclave(Rectangular)
2.Digital Temperature Meter
3. Steam Trap
3. Triple Walled
4. Low Water Cut off
5. Pressure control switch with electric panel
6. Pressure gauge
7. Water indicator
8. Separate Boiler
9. Multiport Valve
10. Heater 220/240Volts
11. Tubular Stand Mild Steel powder coated
12. For Tubular Stand Stainless steel also available with extra charges.
Horizantal Autoclave(Rectangular)	Horizantal Autoclave(Cylindrical)
