AUTOCLAVE (VERTICAL)
Product Details:
Used for Dry Sterilization, steam pressure of 10 to 20 P.S.I,(adjustable) . S.S. inner chamber, Steam jacket and outer wall made of S.S.duly argon arc welded. The space between outer wall & steam jacket is filled with high-grade glass wool to minimize the temperature loss. All sterilizers are hydraulically tested up to 40 P.S.I The lid is made of thick stainless steel and closed by radial type closing arrangement Fitted with a gasket made up of neoprene rubber, safety valves, water level indicator, steam release valve, pressure gauges and S.S. basket. Supplied complete with cord & plug to work on Single Phase 220 / 230 volts A.C. supply.

nner Dimensions (Dia x Height)	250x450mm	300x500mm	350x550mm	450x600mm	550x750mm
Inches Conversion	10 x 18	12 x 20	14 x 22	18 x 24	22 x 30
Capacity	22 ltrs	40 ltrs	50 ltrs	98 ltrs	152 ltrs
Working Load	2.0 KW	2.0 KW	3.0 KW	4.0 KW	6.0 KW
Gasket	Made of Neoprene Rubber
Sterilizing pressure	1.2 kgf / cm (15psi)at 121°c
Pressure Gauge	0-2.1 kgf / cm² (30 psi)
Operating pressure	From 15 to 20psi (Adjustable)
Inner Pressure Tank	Stainless Steel (SS-304)
Top Lid	Mild Steel Plate lined with Stainless Steel from inside
Basket	Made of Stainless Steel
Lid Tightening	Radial Locking system worked by handle
Lid Opening	Paddle lifting device
Water Level Indicator	Fitted on the outer chamber
Boiler – Hydraulically Tested	Upto +40 psi
Accuracy	+ 3 psi
Safety Device	Spring Loaded Type
Water Draining System	Hand Operated Valve
Heating	BY ISI Marked Immersion Heaters
Steam & Vacuum Release	By Valve
Power Supply	220/230V AC, 50/60Hz
