LINEAR IC TRAINER KITS
Product Details:
SPECIFICATION
Micro Logics Linear IC Trainer provides your hands on practical Experience on Digital and TTL electronics at one place and saver the time and Money without compromising the quality standards. The laboratory manual is written for a laboratory course in Digital Circuits to work effectively with TTL Integrated circuits and CMOS integrated Circuits.
This trainer kit is specially designed for the use in Engineering Colleges, Polytechnic Institutes, ITI and Science Colleges for students to study and set up Different experiments.
Technical Details:
  Output voltage: +5V/0.5A Fixed DC Voltage, +/-12V DC Fixed, 15-0-15V AC
 Output current: 1A DC Fixed, 500mA Fixed.
 Load Regulation: +/-0.1 % plus 5mv from full load to no load.
 Line Regulation: +/-0.1% plus 5mv for +/-10% change in mains voltage supply.
 Ripple and Noise: Less than 2.5 mV
Description:
Digital IC Trainer is self-contained experiments with the following facilities for TTL and CMOS IC Experiments.
  2 No’s of 16 pin ZIF SOCKET.
 2 No’s of Op amp and Timer Socket.
 2 No’s of 565 IC Sockets.
 4 No’s Different Ranges Potentiometers.
 Different clock signals.
 Different ranges of and Resistors, Capacitors, Inductors, Inductors & Transistors .
 All outputs termination from 2mm terminals.
 Fixed power supplies of +5V/1Amp.
  Fixed power supplies of +/-12V/500mA.
 Unit is protected through short circuit and overload protection
 With 10 no’s of 2m patch chords.
