AC Multifunctional Calibrator
Product Details:
Voltage Control
Output Voltage Range : 1V, 2V, 5V, 10V, 20V, 50V, 75V, 150V, 300V, 600V, 1000V
0.02mV Min. resolution
Basic Error ACV : ± (0.03 %RD + 0.02 %FS)
Current Control
Output Current Range : 10mA, 20mA, 50mA, 200mA, 1A, 2A, 5A, 10A, 25A, 50A, 100A
0.2µA Min. resolution
± (0.03 %RD + 0.02 %FS) Basic Error ACI
Frequency Control
40Hz to 70Hz Frequency Range
± 0.02 Hz Frequency Error
Phase Control Phase angle Range : 0 to 359.99º
Phase Error : ± 0.05º
AC Multifunctional Calibrator
- Views: 23
- Vendor: Technical Systems
- Vendor Type: Manufacturer, Supplier
- Product Code: TS00000036
- Availability: In Stock
