ABX Micros ES 60

FEATURES

•  Integrated barcode reader (identification of patient samples, QC and reagents).
•  Integrated thermal printer (full data printout, including PLT, RBC and WBC curves).
•  User-friendly interface (colour touch screen, virtual keyboard).
•  Data transfer with USB key (archiving to PC, upload of QC target values).
•  Unique reagent pack system.

TECHNICAL SPECIFICATION

Weight	30.9 lb / 16 kg
Power supply	100 V to 240 V - 50 Hz to 60 Hz
Dimensions	16.9 in x 14.2 in x 14.2 / 43 cm x 36 cm x 36 cm (HxLxP)
Printer	Built-in thermal printer
Throughput	50 tests/hour (Closed Tube) - 60 tests/hour (Open Tube)
Data Management	Complete QC menu, logs (reagents, calibration, maintenance, errors, blank cycle), easy operation Transmission of patient & QC results to LAN (local area network) Mono-directional connection
Memory	1000 patients results with histograms
Screen	LCD colour touch screen
Samples
50 tests/hour (Closed Tube) - 60 tests/hour (Open Tube)
Parameters (18)	WBC, RBC, RDW, HGB, MPV, HCT, MCV, PLT, MCH, MCHC, LYM# & LYM%, MON# & MON%, GRA# & GRA%, PDW*, PCT*
Graphics	PLT, RBC, WBC curves
Blood volume	CBC + 3DIFF mode: 10 μL
Stability	48 hours post-draw stability
Operating sample mode	Open tube or Closed Tube
