Trinocular Microscope
Product Details :
Our firm is actively engaged in putting across best assortment of Trinocular Microscope.
Features:
- Long working life
- Hassle free functionality
- Low maintenance
- Optimum weight
- Proper functioning
- Optimum performance
Micron Pathological Trinocular Microscope Model TR-KG-7A Excel Economy is the newly introduced design for Medical colleges, Professionals & Laboratory use with the full features of the advanced research type Pathological Microscope. It has a very modern look & yet at a very afforable price that will surprise the most demanding users. All the objectives are precentered and parfocal to minimise focusing procedures.
Features:
- 45º inclined with 360 degree rotatable monocular tube
- Co-axial built in Mechnical stage , designed with convenient coaxial adjustment for jerkfree smooth slide manipulation throught 50 X 75 mm
- Dust proof quadruple/quintruple ball bearing revolving nose piece with positive click stops
- Co-axial coarse & fine focusing adjustment knobs. Fine motion, graduated to .002 mm
- Substage Abbe type N.A. 1.25 condenser with rack and pinion,with iris diaphragm with built in swing out filter holder
- Steple Grey, chemical resistant, back-on finish
- Exclusive preset focus lock prevents damage to valuable slides and objectives
- Heavy rectangular sturdy base, with built-in illumination 6V - 20W halogen lamp with dust cover packed in styrofoam packing
- Eye Piece: W.F. 10X / 18 mm
Specifications:
Performance of TR-KG-7A | ||||
Objevtive | Achromatic 4X | Achromatic 10X | Achromatic 40X [Spring] | Achromatic 100X Oil [Spring] |
Additional Information:
- Item Code: TR-KG-7A
