Research Metallurgical Microscope
Product Details:

Brand	Labomed
Application	Laboratory
Nose Piece	4

Keeping in mind the ever-evolving needs of our clients, we are devoted towards offering an optimum quality array of Lx400 Research Metallurgical Microscope.
General Specifications:
Incident & Transmitted -LED illumination with variable illumination control
Power Pack (6 V DC)with charger working on 180-250V AC/ 50-60 Hz
Includes a rechargeable battery which provides a minimum of two hours working of a microscope in absence of power supply.
Technical Specifications:
Stand: Single mold Sturdy stand with anti rust materials.
Extended base with hand rests for enhanced stability and comfort.
Viewing bodies: Siedentopf binocular or trinocular tube 30° inclined, 360° rotatable, interpupillary distance adjustable 48-75mm.
Vacuum coated Prism for better transmission and anti fungus character.
Eyepieces: Wide Field focusable paired eyepiece WF10x/20mm, with foldable eye guard, anti-fungus coating
Nosepiece: Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip, anti-fungus coating.
Par-centered & parfocal on CNC machines.
Objectives: RP series DIN infinity corrected plan achromatic objectives 10x, 20x, 40x (spring loaded), 100x Oil (spring loaded) anti-fungus coating.
Specially corrected for metallurgical
Mechanical Stage: Rackless X-axis, double plate mechanical stage size 200 x 160mm X/Y travel range 78 x 54mm.
Low drive movement controls.
Hard coated surface for scratch resistance.
