DuaL Head
Product Details:
VIEWING HEAD: DUAL BINOCULAR VIEWING HEAD(TWO USERS CAN VIEW SIMULTANEOUSLY)
1. Single Mould Rigid Structure with a Window in Arm for easy Carriage
2. Viewing tube: As per Requirement
3. Head Sliding Type 45 Degree Inclined and Rotatable at 360 degree.
4. Quadruple Ball Bearing nose piece with positive click stops.
5. Co-axial Coarse & Fine focusing Graduated to 1Div=.002mm.
6. With Ball Bearing Driven Mechanical stage for X&Y movement of slide.
7. Movable abbe Condensor N.A.1.25 with iris diaphragm with swingout filter holder.
8. Built in Illumination LED with intensity control.
9. Steple Grey, chemical resistant, back-on finish.
10. Complete with Instruction Manual and dust cover.
11. Duly packed in styrofom packing.
OPTICAL COMBINATION
EYE PIECES: WF 10X/18mm
OBJECTIVES: 4X, 10X, 40X S/L, 100X S/L [Achromatic]
MAGNIFICATION: X40 – X1000
