A. Kaplan Turbine

Type

: Axial Flow Reaction Turbine

Capacity

: 5 HP

Rated Speed

: 1500RPM

Discharge Capacity

: 4500 Liters/Minute

Supply Head

: 7 Meters

Guide Vanes

: Gun Metal Vanes (Aerofoil Blade Shaped)

B. Loading

Rope Brake

Material

:Cast Iron

Drum Size

:300 mm diameter

C. Supply Pump Set

Size

: 10 X 10

Discharge

: 5000 Liters/Minute

Total Head

: 8 Meters

Motor Capacity

: 20 HP

Starter for Motor

: Star Delta Crompton Make

D. Flow Measurement

Material

: C.I Body

Manometer Fluid

: Mercury

E. Pressure Measurement Pressure & Vacuum gauge

F. RPM Indicator

: Digital

G. Sump Tank:

Material of Construction

: MS Powder Coating /M.S. FRP Lining/S.S Unit

Service Required

: Electrical supply-7.5 HP, 3Phase, 440 Volts, 50HZ AC Supply
