System Function
- Readout range – 0.000~4.000Abs
- Plate type – 96-well plate
- Measure system – 8-channel optical system
- Wavelength – 405, 450, 492, 630nm, two more optional filters
- Band width and accuracy – 8nm ± 2nm
- Light source – Monochromatic LED
- Reading speed – 5s with single wavelength for whole plate
- Display – 7″ TFT LCD, 800×480 pixels
- Printer – Built-in printer, external printer
Working Condition
- Power Supply – AC 100-240V, 50/60Hz
- Temperature – 10~35°C
- Humidity – 15~85%
- Interface Repeat ability- <1% RS-232, 4 USB ports, SD card
- Linearity – R≥0.995
- Stability -<0.005Abs/10min
- Shaking – 3 shaking modes with variable time
- Input – Mouse, membrane keyboard, touch screen
- Dimension (mm) – 400(L)x310(W)x169(H)
- Weight – 6 kg
