Potentiometric Titrator
Product Details:
Labindia Analytical Potentiometric Titrator Titra+ comes with quick interchangeable imported burette assemblies with intelligent recognition for its volume size.This potentiometric autotitrator is perfect for all types of industrial applications. The Titra+ has composite differential electrode amplifier unit for potentiometric and voltametric/Karl Fisher titration having connectivity to various electrodes.
Three standard modes of titration namely incremental, equilibrium and cut-off mode is provided to perform all types of titrations. There is a real time clock for time display and report printout with run time indication. With a balance interface to directly transfer the weight. 50 methods can be stored and report of method parameter can be printed in Titra+.

Principle	Volume determination by equivalence point, end point or pH STAT
Control	Microcontroller based (Advanced version of microprocessor).
mV range	± 3200 mV
Accuracy	±0.1mV (±0.0016 pH)
Amplifier input impedance	> 10"12 ohms
Burette Resolution	1/20000 for 1o ml volume
Burette Volume	5 ml, 1o ml & 25 ml available
Filling time	<20 sec
Keyboard	Alphanumeric splash waterproof polyester soft keys
Display	40 x 2 line back lighted liquid crystal display (LCD)
Titration Head	(a) Manual stand with swivelling arm
Stirrer System	Microcontroller based variable speed, high torque vortex stirrer with digital indication. Magnetic Stirrer optional.
Sensors	(1) Electrodes for Potentiometric titration - {pH, Ion, Redox, Argentometric). a) Any combination electrode. b) Differential Electrode System comprising sensing (Indicator) Electrode with BNC Connector and Reference Electrode with 4mm Banana Connector. (2) Electrode for KFNoltametric titration with BNC/TNC Connectors. (3) Temperature sensor (PRT/PT100)
Calibration	3-point Calibration with user entered buffer values and standardisation with 7 pH buffer
End Point detection	a) Potentiometric, b) Voltametric, c) Thermometric and Photometric.
Cut-off criteria	a) Volume b) End point c) mV/pH
Methods	1) Titrations – a) Acid base, b) Nonaqueous c) Redox d) Preciptiation e) Complexometric f) back titration 2) KF titration (Optional)
Results	a) Molarity b) % Assay (wt) c) % volume (ml) d) ppm e) mg/I ijmg/g g) g/I h) meq/I I) moVkg j) TAN and TBN for oil samples.
Method Storage	50 methods with parameters.
Titrant Molarity storage	20 Values
REPORT FORMAT	1) Method parameter. 2) Titration analysis report. 3) Titration analysis condensed report. 4) Titration data table. 5) Titration graphic report - i) µIv/s mV ii) µIv/s First derivative iii)µIv/s Second derivative iv) µIv/s Time 6) Auto evaluation report 7) Statistics report 8) End Point Titration report 9) Calibration report
Input/Output peripheral interface	a) Parallel Port :1No. for printer b) Serial Port : 2 Nos. for Balance & PC
