| Volume determination by equivalence point, end point or pH STAT |
|
| Microcontroller based (Advanced version of microprocessor). |
|
| |
| |
Amplifier input impedance |
| |
| |
| 5 ml, 1o ml & 25 ml available |
|
| |
| Alphanumeric splash waterproof polyester soft keys |
|
| 40 x 2 line back lighted liquid crystal display (LCD) |
|
| (a) Manual stand with swivelling arm |
|
| Microcontroller based variable speed, high torque vortex stirrer with digital indication. Magnetic Stirrer optional. |
|
| (1) Electrodes for Potentiometric titration - {pH, Ion, Redox, Argentometric). a) Any combination electrode. b) Differential Electrode System comprising sensing (Indicator) Electrode with BNC Connector and Reference Electrode with 4mm Banana Connector. (2) Electrode for KFNoltametric titration with BNC/TNC Connectors. (3) Temperature sensor (PRT/PT100) |
|
| 3-point Calibration with user entered buffer values and standardisation with 7 pH buffer |
|
| a) Potentiometric, b) Voltametric, c) Thermometric and Photometric. |
|
| a) Volume b) End point c) mV/pH |
|
| 1) Titrations – a) Acid base, b) Nonaqueous c) Redox d) Preciptiation e) Complexometric f) back titration 2) KF titration (Optional) |
|
| a) Molarity b) % Assay (wt) c) % volume (ml) d) ppm e) mg/I ijmg/g g) g/I h) meq/I I) moVkg j) TAN and TBN for oil samples. |
|
| 50 methods with parameters. |
|
| |
| 1) Method parameter. 2) Titration analysis report. 3) Titration analysis condensed report. 4) Titration data table. 5) Titration graphic report - i) µIv/s mV ii) µIv/s First derivative iii)µIv/s Second derivative iv) µIv/s Time 6) Auto evaluation report 7) Statistics report 8) End Point Titration report 9) Calibration report |
|
Input/Output peripheral interface |
| a) Parallel Port :1No. for printer b) Serial Port : 2 Nos. for Balance & PC
|
|
| |
