Digital Online Dew Point Analyzer

Product Details:

Usage/Application	Industrial
Measuring Range	-60 to + 30 Deg C
Brand	Applied Techno Systems
Accuracy	+/- 2%
Moisture Range	0 - 23000 PPM
Material	MS
Display Type	LCD Display
Country of Origin	Made in India
Vapor Pressure	0-17.5mm Hg
Analog Output	4-20 mA
Max Pressure	12kg/cm2
Response Time	10 sec for 63% Step Change
Power Required	220V/50Hz,110 V/50Hz optional

Digital Online Dew Point Analyzer Ideal for precise monitoring of moisture or dew point in air or gas output from dryers system or in process. Continous monitoring of dew point results in reduced maintance costs and downtime caused by separated moisture, The main cause of corrosion in pneumatic systems. the analyzer usesa highly accurate capacitive integrated thin film water vapor sensor,and is an economic alternative to the chilled-mirror dew point type meters. It utilizes microprocessor based circuits to give a direct read out in dew point or other units and other units corresponding to sensor output based on psychometric equations. To achieve higher accuracies it uses temperature compensation over complete operational range.The insturment is contained in a high impact plastic housing.
Application:

• Compressed air

• Industrial process control

• Drying system

• Protection systems

• Glove box

• Turbines

• HVAC & Breathing air

Specification:
