Product Details :

E-Catalogue

TECHNICAL PARAMETERS

• Absorbency range: – 0.3-3.0ABS
• Resolution: 0.001 Abs(display),0.0001 Abs(inner calculation)
• Light source: Halogen Lamp
• Wavelength: 340,405,510,546,578,620nm + 2 free positions
• Stability:<0.005A/30min.
• Half-bandwidth: ≤12 nm
• Temperature control: Room Temperature, 25°C, 30°C, 37°C
• Temperature accuracy: ±0.1°C
• Colorimetric cell: 3Oµ1 quartz flow cell
• Injection: 0~6000µl
• Cross Contamination: ≤1.0%
• Storage: 500 test items and 10000 test results
• Interface: Standard RS232 interface, 4 USB interfaces, Ethernet interface
• Display: 7″color LCD
• Print: Built-in high-speed thermal printer, and connect external printer
• Processor: Embedded high-speed processor
• Weight: 10kg
• Dimension: 410(L) x 340(W) x 150(H)mm
• Power Supply: 100~240VAC, 50Hz/60Hz

FEATURES

• Based on the Linux operating system, color graphical interfaces, large and color LCD
• Operating with touch screen, function keys and external USB mouse or keyboard, which is simple and fast.
• Multiple measurement methods (End point, Two-point, kinetics, double wavelength) are optional, and multiple calculation methods (factor, linear regression, nonlinear regression, etc.) are also optional.
• Store 500 test items and 10000 test results; supply many methods of printing and many formats of report.
• Each item can be set for two quality-control, automatically statistic and draw QC curve, store one year’s QC data and QC chart, also can query and print.
• Auto-dormancy for the lamp to prolong its life.
• Power-off protective function to automatically save measurement results.
• Self-check function for alarming to light route, liquid route and machine components, etc.
• With standard interface for communication, convenient for data transmitting and processing.
